Replacement tank LRA 150L Toyota Land Cruiser HZJ105
Couldn't load pickup availability
- 100% secure payment
- Equipment Tested & Approved
- Fast & Careful Shipping
Questions about this product?
We are here to help you.
The replacement tank LRA is designed for Toyota Land Cruiser HZJ105 diesel Wagon 4WD body, from 1998 to 2006. With its capacity to 150 liters, It replaces the original front main tank in order to increase fuel range for travel, tracks, raids and travel in isolated areas.
This tank is located on the left side of the driveshaft, with the standard exhaust and original filler neck retained. It is intended for models with a rigid axle and manual transmission only and is not suitable for versions with independent front suspension. The instructions specify that operation remains identical to the original, reusing several components from the original tank, including the anti-rollover valve and the fuel gauge/fuel inlet assemblies.
Since 1989, LONG RANGE AUTOMOTIVE designs and manufactures its tanks in Australia. Each model is developed for a specific vehicle application to optimize available volume while respecting the chassis's mechanical constraints. The tanks LRA They are made of 2mm T125CQ steel. They incorporate internal baffling to limit fuel movement, as well as an expansion chamber. Before being sold, they undergo pressure tests and several quality control checks. Tests are also carried out over dozens of kilometers of heavily degraded tracks. These tests verify the tank's resistance to vibrations, repeated twisting, impacts, and the stresses of prolonged off-road use.
Technical specifications:
- Type: Replacement tank
- Capacity: 150 liters
- Vehicle compatibility: Toyota Land Cruiser HZJ105
- Compatible years: 1998 to 2006
- Compatible engine type: Diesel
- Body type: Wagon
- Transmission: 4WD
- Required configuration: Rigid axle, manual transmission only
- Replaced tank: Original front main tank
- Position: Left side of the driveshaft
- Exhaust: Standard
- Filling point: Standard
- Fuel gauge: Functioning maintained as originally designed, with adaptation and replacement of the gauge/fuel inlet assemblies
- Spare wheel: Retained
- Specific incompatibilities: Not compatible with independent front suspension
- Estimated assembly time: 4 hours
- Made in Australia
